Position: Home > Products > PVC Flat Cable

UL 2651 PVC FLAT RIBBON CABLE

Rated Temperature: 105℃

Rated Voltage: 300V

Conductor: Stranded or solid copper

Insulation: Lead Free PVC

P NO.: 2-100P

Application: For internal wiring of electronic and electrical equipment

UL Certification Feedback

Details

Conductor導體				Insulation 絕緣			Resistance at20℃	Pack包裝
線號	條數(shù)	線徑	外徑	厚度	完成直徑	排數(shù)	20度導體電阻Ω/KM	米/卷
AWG	NO.	Dia.	Dia.	Thick	O.D*P	P NO.	20度導體電阻Ω/KM	M/coil
30	7	0.100	0.30	0.38	1.06	2	354.00	610
28	7	0.127	0.38	0.38	1.14	2	223.00	610
26	7	0.160	0.48	0.38	1.24	2	139.00	610
24	11	0.160	0.61	0.38	1.37	2	88.90	610
22	17	0.160	0.76	0.38	1.52	2	51.35	610
20	21	0.180	0.95	0.38	1.71	2	32.85	610
18	41	0.160	1.18	0.38	1.94	2	23.30	610
16	26	0.254	1.49	0.38	2.25	2	13.32	610
30	7	0.100	0.30	0.38	1.06	3	354.00	610
28	7	0.127	0.38	0.38	1.14	3	223.00	610
26	7	0.160	0.48	0.38	1.24	3	139.00	610
24	11	0.160	0.61	0.38	1.37	3	88.90	610
22	17	0.160	0.76	0.38	1.52	3	51.35	610
20	21	0.180	0.95	0.38	1.71	3	32.85	610
18	41	0.160	1.18	0.38	1.94	3	23.30	610
16	26	0.254	1.49	0.38	2.25	3	13.32	610
30	7	0.100	0.30	0.38	1.06	4	354.00	610
28	7	0.127	0.38	0.38	1.14	4	223.00	610
26	7	0.160	0.48	0.38	1.24	4	139.00	610
24	11	0.160	0.61	0.38	1.37	4	88.90	610
22	17	0.160	0.76	0.38	1.52	4	51.35	610
20	21	0.180	0.95	0.38	1.71	4	32.85	610
18	41	0.160	1.18	0.38	1.94	4	23.30	610
16	26	0.254	1.49	0.38	2.25	4	13.32	610
30	7	0.100	0.30	0.38	1.06	5	354.00	305
28	7	0.127	0.38	0.38	1.14	5	223.00	305
26	7	0.160	0.48	0.38	1.24	5	139.00	305
24	11	0.160	0.61	0.38	1.37	5	88.90	305
22	17	0.160	0.76	0.38	1.52	5	51.35	305
20	21	0.180	0.95	0.38	1.71	5	32.85	305
18	41	0.160	1.18	0.38	1.94	5	23.30	305
16	26	0.254	1.49	0.38	2.25	5	13.32	305
30	7	0.100	0.30	0.38	1.06	6	354.00	305
28	7	0.127	0.38	0.38	1.14	6	223.00	305
26	7	0.160	0.48	0.38	1.24	6	139.00	305
24	11	0.160	0.61	0.38	1.37	6	88.90	305
22	17	0.160	0.76	0.38	1.52	6	51.35	305
20	21	0.180	0.95	0.38	1.71	6	32.85	305
18	41	0.160	1.18	0.38	1.94	6	23.30	305
16	26	0.254	1.49	0.38	2.25	6	13.32	305
